Attenuators AT35A-AT10A/ATP35-ATP10

Models AT35A-AT10A/ATP35-ATP10 - Attenuators

The AT-Series of attenuators allows the output level of a network of 25V or 70V speakers to be controlled from a wall-mounted volume control, without affecting overall amplifier volume settings. The AT10A can handle speaker loads of up to 10W and the AT35A can handle speaker loads of up to 35W. Volume reduction takes place in 3 dB increments except for the two lowest settings, which provide 6 dB reduction increments. These rugged attenuators have 10 levels of sound control, plus an off setting.

The ATP-Series of attenuators allows the output level of a network of 25V or 70V speakers to be controlled from a wall-mounted volume control, without affecting overall amplifier volume settings. A bypass function overrides the volume control knob setting when activated by 9V to 30V DC. Applying 9V to 30V DC between pins labeled D+ and D- bypasses the volume control function and provides full volume audio to the speakers. The ATP-Series attenuators feature etched faceplate markings.

  • Adjusts loudspeaker output levels on 25V and 70V systems
  • Bypass function allows important and emergency announcements to be heard at the highest level even if local attenuator volume is set low or off
  • 2 models control up to 10-watt and 35-watt speaker systems¬† (ATP10/ATP35)
  • 10 attenuation steps and an off setting
  • Attenuation in 3 dB increments except for two lowest settings, which provide 6 dB reduction increments
  • Mounts in standard electrical box, single (AT10A/ATP10) or double (AT35A/ATP35)
  • Convenient pluggable screw terminal connections (ATP10/ATP35)
  • Simple connections
