The MC512C Power Supply is the main power supply for the Multicom 2000® system. The Model MC512C power supply is a fully regulated, switching power supply providing an output voltage of +5V @ 15.0A, -5V @ 0.5A, +12V @ 5.5A, and -12V @ 0.5A. Ripple is less than 20mV p-p on any output. Power consumption is 75W maximum under normal operating conditions with a 120-station system.
An internal 3A fuse protects the power supply. Two 6-position, 0.156 centerline, polarized connectors, and four 4-position polarized output connectors are provided. The power supply gets its power from the three-wire receptacle located in the MCBBC enclosure. It provides an on/off switch for the Multicom 2000 system when installed.
- +5V @ 15.0A, -5V @ 0.5A, +12V @ 5.5A, -12V @ 0.5A
- Fully regulated switching supply
- Ripple is less than 20mV on any output
- Power consumption is 75W maximum under normal operating conditions with the 120 station system
- Protected by internal 3.0A fuse
- Has two 6-position, 0.156 centerline, polarized connectors, and four 4-position polarized output connectors
- Provides power for all boards and card cage fans
- Mounts to the MCRMP or MCMP
Dimensions: 5-7/8″ W x 3-3/8″ H x 6-1/2″ D
Product Weight: 4 lb.
Power: 120V AC
